V86B高压焊接球阀它具有旋转90度的动作，旋塞体为球体，有圆形通孔或通道通过其轴线。球阀在管路中主要用来做切断、分配和改变介质的流动方向，它只需要用旋转90度的操作和很小的转动力矩就能关闭严密。球阀适宜做开关、切断阀使用，但近来的发展已将球阀设计成使它具有节流和控制流量之用，如V型球阀。

       V86B高压焊接球阀为活接焊接式，自带焊接短管，另外常用还有卡套连接和内螺纹连接。V86B本身结构紧凑，密封稳定，结构简单，维修方便，密封面与球面常在闭合状态，不易被介质冲蚀，易于操作和维修，适用于水、溶剂、酸和天然气等一般工作介质，而且还适用于工作条件恶劣的介质，如氧气、过氧化氢、甲烷和乙烯等，在各行业得到广泛的应用。球阀阀体可以是整体的，也可以是组合式的。

V86B高压焊接球阀优点：

       1．流体阻力小，全通径的球阀基本没有流阻。

       2．结构简单、体积小、重量轻。

       3．紧密完好。它有两个密封面，而且目前球阀的密封面材料广泛使用各种塑料，密封性好，能实现完全密封。在真空系统中也已广泛使用。

       4．操作方便，开闭迅速，从全开到全关只要旋转90°，便于远距离的控制。

       5．维修方便，球阀结构简单，密封圈一般都是活动的，拆卸更换都比较方便。

       6．在全开或全闭时，球体和阀座的密封面与介质隔离，介质通过时，不会引起阀门密封面的侵蚀。

       7．适用范围广，通径从小到几毫米，大到几米，从高真空至高压力都可应用。

       8．由于球阀在启闭过程中有擦拭性，所以可用于带悬浮固体颗粒的介质中。

V86高压焊接球阀产品概述

V86高压焊接球阀是一种适用于高压工况的阀门，常由DK-LOK等公司生产。以下是其产品概述：

 V86高压焊接球阀 - 压力等级：工作压力较高可达10000psi（约689bar），能满足多种高压系统需求 。

V86高压焊接球阀 - 结构设计：采用阀杆内置的防爆设计，可防止阀杆吹出，提升使用安全性。手柄方向指向流向，且配有手柄定位销，能主动防止手柄过旋泄露。有两通和三通等不同结构，三通球阀可提供侧进和传统底进等多种流道配置，满足不同流向控制需求 。

V86高压焊接球阀 - 材质与密封：阀体等部件常采用316不锈钢等材质，强度高。密封材料有多种选择，如PTFE等，可适应不同介质和工况，且经过严格氮气泄漏测试，密封性能稳定 。

V86高压焊接球阀 - 连接方式：具有多种端部连接类型，包括卡套式、NPT螺纹、BSPT螺纹等，可满足广泛的系统连接要求 。

V86高压焊接球阀 - 性能优势：具备大通径、高流量设计，流体阻力小，能有效提高介质输送效率。操作简便，可实现90°快速启闭，且维护方便，适用于多种复杂工况 。

Product Overview of V86 High - pressure Welded Ball Valve

 The V86 high - pressure welded ball valve is a kind of valve suitable for high - pressure working conditions, often produced by companies such as DK - LOK. The product overview is as follows:

 V86 high - pressure welded ball valve - Pressure Rating: The working pressure can be as high as 10,000 psi (about 689 bar), which can meet the requirements of various high - pressure systems .

 V86 high - pressure welded ball valve - Structural Design：It adopts a blowout - proof design with an internally loaded stem, which can prevent the valve stem being blown out improve the use safety. The handle indicates the flow direction, is equipped with a handle stop pin, which can actively prevent the handle over - rotating leaking. It has different structures such as two - way three - way. The three - way ball valve can provide various flow channel configurations such as side - entry traditional bottom - entry to meet different flow direction control requirements .

 V86 high - pressure welded ball valve - Material Sealing：The valve body other components are often made of 316 stainless steel other materials, with high strength. There are various choices of sealing materials, such as PTFE, etc., which can adapt to different media working conditions. it has passed the strict nitrogen leakage test, with reliable sealing performance .

 V86 high - pressure welded ball valve - Connection Mode: It has a variety of end - connection types, including compression type, NPT thread, BSPT thread, etc., which can meet a wide range of system connection requirements .

 V86 high - pressure welded ball valve - Performance Advantages: It has a large - diameter high - flow design, with small fluid resistance, which can effectively improve the medium transportation efficiency. It is easy to operate, can achieve 90° quick opening closing. Moreover, it is convenient to maintain suitable for a variety of complex working conditions .
