20000PSI超高压终端接头

20000PSI超高压终端接头是专为极端高压系统设计的终端连接解决方案，额定工作压力达20000PSI（138MPa）。本产品采用整体锻造工艺和多重密封技术，确保在石油天然气、化工处理、军事装备等领域的超高压管路终端实现安全稳定的密封连接。

20000PSI超高压终端接头核心特点：

20000PSI超高压终端接头承压能力：通过20000PSI（138MPa）压力认证，符合ASME B16.34标准要求

军事级材质：选用AISI 4340高强度合金钢或17-4PH沉淀硬化不锈钢

20000PSI超高压终端接头复合密封系统：金属锥面主密封+PTFE辅助密封的双重保障

防松脱设计：集成锁紧螺纹和防转销结构

环境适应性：表面镀硬铬处理，耐腐蚀性能满足NACE MR0175标准

20000PSI超高压终端接头典型应用场景：

深海油气开采超高压管汇终端

化工超临界反应装置管路终端

军事高压试验系统终端连接

超高压水射流设备终端接口

注：建议补充说明"使用前需进行压力测试，确保密封性能"，并可根据具体型号标注适用的温度范围（如-50°C至+400°C）和介质兼容性参数。

20000PSI Ultra-High Pressure Terminal Connector Product Overview

The 20000PSI Ultra-High Pressure Terminal Connector provides ultimate end connection solution for extreme pressure systems, rated at 20000PSI (138MPa). Featuring integral forged construction multi-stage sealing technology, it ensures secure termination for ultra-high pressure pipelines in oil & gas, chemical processing military applications.

Key Features:

Extreme pressure capacity: Certified for 20000PSI (138MPa), compliant with ASME B16.34

Military-grade materials: AISI 4340 high-strength alloy steel 17-4PH precipitation hardening stainless steel

Hybrid sealing system: Metal cone primary seal + PTFE secondary seal

Anti-loosening design: Integrated locking threads anti-rotation pins

Environmental resistance: Hard chrome plating meets NACE MR0175 standards

Typical Applications:

Subsea oil & gas ultra-high pressure manifold termination

Supercritical chemical reactor piping ends

Military high-pressure test system connections

Waterjet cutting equipment terminal interfaces
